Product name : High quality maintenance free 12V200AH gel/lead acid battery
Item : QW-BG200A
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:
High quality maintenance free 12V200AH gel/lead acid battery

Applied Scope :

1)Communication Systems:Switch,Microwave Stations,Mobile Base Stations,Data Centers,Radio and Broadcasting Stations.

2)Motivity Field:Robots,Electric Toys,Electric Tools&Portable Vacuum Cleaners.

3)Solar&Wind Power Generation Systems

4)EPS&UPS Systems

→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→

Main Characteristic :

maintenance-Free Operation

Absorbent glass mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance.During the expected float service life of batteries,no need to check the specific gravity of the electrolyte or add water.

Good Discharging Ability

Tight assembly technology ensures an excellent high-rate discharge performance.

Long Service Life

A unique corrosion-resistant grid alloy ensures Prostar batteries have long service life.

Low Self Discharge

Using high purity raw materials ensures Prostar batteries have less self-discharge.

Environmental & Non-polluting

Gas Recombination technology ensures the battery high seal reacting rate,which can prevent the acid fog from separating out.

→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→

Technical Specification :

Nominal Voltage

12V

 Nominal Capacity (10 hour rate)

200Ah

Capacity

25oC

(77°F)

20 hour rate (11.0A)

220Ah

5 hour rate (35.4A)

177Ah

1 hour rate (132A)

132Ah

Internal Resistance

Full Charged Battery 25oC

≤2.5mΩ

Capacity affected by Temperature

(10 hour )

40oC

(104°F)

102%

25oC

(77°F)

100%

0oC

(32°F)

85%

-15oC

(5°F)

65%

Self-Discharge

25oC

(77°F) Capacity

after 3 month storage

90%

after 6 month storage

80%

after 12 month storage

62%

Charge (Constant Voltage) 25oC

(77°F)

Float

Initial Charging Current Less than 40A

Voltage 13.6-13.8V

Cycle

Initial Charging Current Less than 40A

Voltage 14.4-14.9V

Battery Dimensions

Length

522mm

Width

240mm

Height

219mm

Total Height

224mm

Box Dimensions

Length

537mm

Width

255mm

Height

299mm

Quantity Per Box

1 PC per box

Net weight Per Cell

54.0 kg±500g

Net weight Per Box

54.0kg

Gross Weight

55.0kg

Note The above data are average values, and can be obtained within 3 charge/discharge cycles. These are not minimum values. Cell and battery designs/specifications are subject to modification without notice. Contact Prostar for the latest information.
