Products > Solar Panel > Mono Solar Panel > 300W Mono Solar Panel
Product name : 300W Mono Solar Panel
Item : QW-M300W
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:
  300W Solar Panels, PV Mono Solar Panel for Grid solar system

Renewable energy is energy that comes from natural sources that are almost always available, such as sunlight, wind, rain, tides, and even heat. Since creating environmentally-friendly energy solutions is crucial, the renewable energy industry has become a key business that will only increase in importance in future years and decades. Solar energy is often regarded as the most efficient renewable energy source for generating electricity.

Features:
1. High cell efficiency with quality silicon materials for long term output stability and reliability.
2. Rigorous quality control to meet highest international standards.
3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance
4. Unique frame design, high mechanical strength, and easy Installation.
5. Advanced encapsulation material with multiplayer sheet lamination to provide efficient protection from the severest environmental conditions
6. Outstanding electrical performance under high temperature and low irradiance conditions

Solar cells applications:
1. Any large or small on-grid or off-grid solar power stations
2. Commercial and industrial building roof-top systems
3. Residential roof-top systems
4. Any commercial or industrial ground mount systems
5. Other industrial or commercial applications

Solar panel quality and warranty:
1. Peak power of single module in guaranteed in +-3%power tolerance.
2. Average power of modules in single order is guaranteed not less than the peak power
3. Rigorous quality control meets the highest international standard
4.5 years limited warranty on material and workmanship
5.10 years and 20 years limited warranty for minimum power output.

Technical Specifications:

Module Type

QW-M260W

QW-M270W

QW-M280W

QW-M290W

QW-M300W

Maximum Power at ST(Pmax)W

260Wp

270 Wp

280Wp

290 Wp

300Wp

Maximum Power Voltage(Vmp)V

36/18

36/18

36/18

36/18

36/18

Maximum Power Current(Imp)A

7.2/14.4

7.5/15

7.77/15.55

8.05/16.11

8.33/16.66

Open Circuit Voltage(Voc)V

39.15/19.1

39.2/19.3

39.3/19.4

39.3/19.4

39.6/19.8

Short Circuit Current(Isc)A

7.8/15.6

8.03/16.05

8.13/16.26

8.86/17.72

9.16/18.33

Cell Efficiency(%)

15.57%

16.5%

16.7%

17.3%

18.1%

Module Efficiency(%)

14.8%

15.4%

15.9%

16.5%

17.2%

Operating Temperature°C

-40°C to +85°C

Maximum system voltage

1000V(IEC)DC

Power tolerance

+-3%

Temperature coefficients of Pmax

-0.45%/°C

Temperature coefficients of Voc

-0.27%/°C

Temperature coefficients of Isc

0.05%/°C

Weight(kg)

25.5

Number of cell(pcs)

6*12

Dimensions(mm)

1920*1000*50/35
