Inverter is a power equipment that can change DC(storage battery, solar cell, wind dynamo etc.) to AC.
This inverter use high frequency power conversion technology and the ferrite transformer instead of the old bulky silicon steel transformer, that is why power inverter is lighter, smaller than other similar inverter.
-
CE & Rohs & SGS was approved.
-
Upgrade big aluminium housing case and intelligent cooling fans, improve cooling ability, save enery and lengten the use life.
-
Voltage display: digital display
-
Maximum 2000W continuous output and 4000W surge power.
Technical Parameter:
Model No. |
MSW-2000 |
Rated power |
2000W |
Peak power |
4000W |
Transfer efficiency |
≥94% |
Input voltage |
12Vdc |
24Vdc |
Input voltage range |
10-15Vdc |
20-30Vdc |
Output voltage |
110Vac |
220Vac |
Output voltage range |
110Vac±5% or 220Vac±5% |
Voltage display |
digital display |
Frequency |
50Hz±2% or 60Hz±2% |
No load current |
<0.85A |
<0.5A |
Waveform |
Modified Sine Wave |
Low voltage alarm(DC) |
10.5Vdc |
21Vdc |
Low voltage protection(DC) |
10Vdc |
20Vdc |
Over voltage protection(DC) |
15.5Vdc |
31Vdc |
USB port |
yes |
Over-load Protection |
2000W-2100W |
Cooling Way |
Intelligent Cooling Fans |
Fan Start Temperature |
≥40±5℃ |
Temperature Protection |
70±5℃ |
Packaged |
1*pair battery cable(red & black)
1*english user manual
1*neutral packing box |
Dimension |
Inverter: 281*150*100mm/5.5kg
Carton: 460*260*170mm/14kg/2pcs |
Certifications |
CE、Rohs |
Protect functions:
1. Over load protection
2. Over current protection
3. Over voltage protection
4. Low voltage protection
5. Surge protection
6. Short circuit protection
7. High temperature protection
8. Reverse connection protection
9. Internal fuse protection
10. Leakage Protection
Applicable for: ( Solar/Wind/Home System )
1. Travel set equipment
2. Industrial equipment
3. Office equipment
4. Kitchen equipment
5. Household electrical equipment
6. Power tools
